Cold Heading Wire

High Hardness Cold Heading Wire 316/316C/316LA Matte Surface

High Hardness Cold Heading Wire 316/316C/316LA Matte Surface

Cold Heading Wire has high hardness, yield strength and tensile strength, it mainly used for various kinds of fasteners manufacturing.

High Hardness Cold Heading Wire 316/316C/316LA Matte Surface


MaterialStainless steel/ Alloy steel
Grade300series (301, 302, 304, 304L, 304H, 304N, 304ES, 316L, 316C,316LA...) 130M, 200CU, 201CU, 202, , 410, 420, 430,etc
65Mn, 70#, 72A, 72B, 55SiCr, 50CrVA, 60Si2MnA, 65Si2CrV, SAE9254, etc.
StandardASTMA229/A230/A401/A877, JSG3560/3561/4309, EN 10088-3, GB/T4240,  etc
Sizeφ0.15mm-φ16mm; or according to customers' requests
SurfaceBright, matte ,downy, electrolysis bright ,cloudy ,plain ,black,etc
ConditionAnnealed and Soft, 1/2 hard, 3/4 hard and full hard
TypeCold Heading Wire (B-SPR/D-SPR)
PackingWoven bag, core, wooden reel, etc




316 stainless steel wire has a higher nickel content and 2-2.50% molybdenum, giving the alloy better corrosion resistance. With its superior cold working properties, it can be used in severe cold forming operations and exhibits short time tensile and creep strength properties at elevated temperatures.


Steel GradeDINChemical composition
CSiMnPSNiCrMoOther composition
316WNr1.4436≤0.08≤1.0≤2.0≤ 0.045≤ 0.03010.0-14.016.0-18.02.0-3.0
316(ROPE)
0.0530.41.50.0350.0110.8172.2
316C
≤0.0850≤2.0≤ 0.040≤ 0.03010.0-14.016.0-18.02.0-3.0Cu:≤2.8-3.8
316LAWNr1.4404≤0.03≤0.75≤2.0≤0.045≤ 0.03010.0-14.016.0-18.02.0-3.0N:≤0.10
316LJWNr1.4435≤0.08≤1.0≤2.0≤0.045≤ 0.03012.0-15.016.0-18.02.0-3.0N:≤0.10
316N
≤0.08≤1.0≤2.0≤0.045≤ 0.03010.0-14.016.0-18.02.0-3.0N:0.10-0.16
316NB
0.03-0.050.4-0.71.4-1.6≤ 0.0400.02-0.0312.0-13.017.5-18.02.0-3.0Ti:0.005-0.05,Nb:0.004-0.06
316F
≤0.08≤1.0≤2.0≤0.045≤0.01010.0~14.016.0-18.02.0~3.0
316LF
≤0.03≤1.0≤2.0≤0.045≤0.01010.0-14.016.0-18.02.0~3.0
316TIWNM.4571≤0.08≤1.0≤2.0≤0.045≤ 0.03010.0-14.016.0-18.02.0-3.0Ti:≤0.7
316UL
≤0.02≤1.0≤2.0≤0.045≤ 0.03012.0-15.016.0-18.02.0-3.0Cu:≤0.6,N:≤0.08
316/316L
≤0.03≤1.0≤2.0≤0.045≤0.03010.0-14.016.0~18.02.0-3.0N:≤0.10




Application for stainless steel wire:



316: Used In Seawater (Bolt,Screw Cap And So On)
316(Rope): Tight Wire Used In Seawater
316C: Bolt Used In Seawater
316LA: Fine Wire,Chemistry Article
316LJ: Fine Wire
316N: High Strength Wire Netting
316F: Profiled Rolling (Watch Band, Kitchenware)
316LF: Profiled Rolling (Watch Band, Kitchenware)
316TI: The Automobile Exhaust Parts (Corrugated Pipe Scarfskin)
316UL: Weaving
316/316L: High Inoxidizability

Steel GradePhysical Property
Y.ST.SEL.HRB
3162405806471
316(ROPE)2275515874
316C2506105587
316LA
54962
316LJ2135605579
316N21256055
316NB22054070
316F2305705870
316LF2255654666
316TI2145656579
316UL21253958
316/316L2275516672


Cold heading is the process of forging metal at temperatures close to room temperature without any additional heat. The hardness, yield strength and tensile strength of the metal can be improved by cold working.

Cold heading wire is mainly used for various kinds of fasteners manufacturing, for example: precision screws, bolts and nuts etc. And also in manufacturing rivet, nail, stable, pins for construction and automotive.


MTSCO is a professional supplier of steel wire with complete production technology and rich management experience. We produce spring wire, electrolytic polished wire, fine wire, wire for netting, hose wire, welding wire, cold heading, locking wire, and other products. Our main materials are stainless steel and alloy steel, and the raw materials we use are from the biggest and most well-known steel mills in China, we can supply wire in sizes ranging from 0.15 mm to 16 mm in diameter. Our factory is well-equipped and our products conform to ASTM, DIN, GTB, JIS, JSG, and other international standards. We have experienced foreign trade staff with high-quality service and can produce high-quality products according to customers' requirements.

Quality Control

Production process of stainless steel wire

Why Choose MTSCO?

Integration of industry and trade

Provide you with cost-effective products and professional services.

One stop procurement of stainless steel wire products

Leave the complexity to Mtsco and the simplicity to you.

After the test of time for 17 years

Whether the products, services, capital and strength, Mtsco is your optimum partner.
